参数规格
| 规格 | 外形尺寸 | |||||
|---|---|---|---|---|---|---|
| ΦD | ΦD1 | Φd | l(mm) | L1(mm) | L2(mm) | |
| 1-1/2" | 60.3 | 48.0 | 48.6 | 34.9 | 64.0 | 62.0 |
| 2" | 73.3 | 60.0 | 60.6 | 38.1 | 73.0 | 68.0 |
| 2-1/2" | 89.2 | 73.0 | 73.4 | 44.5 | 86.0 | 78.0 |
| 3" | 105.5 | 89.0 | 89.3 | 47.6 | 99.0 | 87.0 |
| 规格 | 外形尺寸 | |||||
|---|---|---|---|---|---|---|
| ΦD | ΦD1 | Φd | l(mm) | L1(mm) | L2(mm) | |
| 1-1/2" | 60.3 | 48.0 | 48.6 | 34.9 | 64.0 | 62.0 |
| 2" | 73.3 | 60.0 | 60.6 | 38.1 | 73.0 | 68.0 |
| 2-1/2" | 89.2 | 73.0 | 73.4 | 44.5 | 86.0 | 78.0 |
| 3" | 105.5 | 89.0 | 89.3 | 47.6 | 99.0 | 87.0 |
